Diaz Sheetsandplates, based right here in Manila, stands as your trusted partner for premium steel solutions. We take pride in manufacturing and supplying high-quality Stainless Steel 415 sheets and plates, committed to meeting the demanding needs of local industries with reliable, homegrown excellence. Our focus is on delivering products that not only meet but exceed expectations, providing the strength and durability your projects require. When you choose us, you’re choosing a local specialist dedicated to supporting the growth and infrastructure of the Philippines with top-tier materials you can count on.
Stainless Steel 415 is a martensitic grade known for a great blend of strength and corrosion resistance. Its composition, primarily iron with around 12% chromium, is balanced to offer good mechanical properties. This steel can be heat treated to achieve impressive hardness and high tensile strength, making it remarkably tough and durable. It maintains respectable ductility, allowing it to be fabricated into various forms without sacrificing its inherent robustness, which is why it’s often selected for challenging environments where both strength and a moderate level of corrosion resistance are necessary.
| Specifications : | ASTM A240 / ASME SA240 |
| Dimensions : | ASTM, ASME and API |
| Standard : | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Surface : | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc. |
| Finish : | Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish |
| Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
| Grade | C | Mn | P | S | Si | Ch | Ni | Mo |
| SS 415 | 0.05 max | 0.50-1.00 | 0.030 max | 0.030 max | 0.60 max | 11.5-14.0 | 3.5-5.5 | 0.50-1.00 |
| Tensile Strength R₃ N/mm² | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 |
| 0.2% Offset Yield Strength Rᵖ ≥N/mm² | 520 | 520 | 520 | 520 | 520 | 520 | 520 |
| Elongation in 2 inches, % | 15 min | 15 min | 15 min | 15 min | 15 min | 15 min | 15 min |
| Grade | WERKSTOFF NR. | UNS | AISI |
| SS 415 | 1.4313 | S41500 | F6NM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Density lbm/in3 | Melting Range(°F) | Thermal Conductivity(BTU-in/hr- ft. °F) | Electrical Resistivity(in x 10-6) | Modulus of Elasticity (psi x 106 | Coefficient of Thermal Expansion (in/in)/°F x 10-6 | Specific Heat(BTU/lb/°F) |
|---|---|---|---|---|---|---|---|
| 415 | -at 68°F: 0.280 | 2700 to 2790 | 187 at 212°F | 23.7 at 68°F | 29 | 6.0 at 32 – 212°F | 0.11 at 68°F to 212°F |
| – | – | – | – | – | 7.5 at 68 – 1200°F | – |
| Metric | density (g/cm³) | x | T | x | W | x | L | = | weight |
|---|---|---|---|---|---|---|---|---|---|
| Example | 4.50g/cm³ | x | 6mm | x | 2m | x | 1m | = | 54.00 kg |
| Imperial | density (lbs/in³) | x | T | x | W | x | L | = | weight |
| Example | 0.163 lbs/in³ | x | 4in | x | 48in | x | 144in | = | 4506.6 lbs |
Stainless Steel 415 Sheet and Plates has several advantages, including superior strength, durability, and corrosion resistance, especially after heat treatment. Its martensitic structure provides excellent corrosion resistance, making it suitable for harsh environments. The durability of the product further enhances its durability and performance in high-pressure applications. In addition, it offers better machinability and lower cracking properties compared to other high-strength materials. Stainless steel 415 is widely used in the manufacture of products such as valves, pumps and equipment, providing reliable performance in both industrial and industrial applications.
The versatility of Stainless Steel 415 sheets and plates makes them ideal for a wide range of demanding applications. You’ll commonly find them used in critical components like turbine blades and fasteners within the aerospace and energy sectors, where their strength at high temperatures is invaluable. They are also perfectly suited for heavy-duty industrial equipment, such as pump shafts and valves, and are a reliable choice for cutting tools and even high-quality kitchen cutlery. Essentially, any situation that calls for a material that can withstand significant stress, wear, and moderate corrosive elements is a perfect fit for 415.
