From the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as your trusted partner for premium stainless steel. We take pride in supplying high-quality Stainless Steel 304L sheets and plates, catering to the diverse needs of businesses across the Philippines. Our commitment is to provide not just a product, but a reliable foundation for your most demanding projects, ensuring you receive materials that combine durability with exceptional value from a local source you can count on.
Stainless Steel 304L is known for its excellent balance of strength and corrosion resistance. Its composition is carefully controlled, with a slightly lower carbon content than standard 304, which helps prevent issues during welding. This grade offers strong mechanical properties, including good tensile strength and excellent formability, allowing it to be easily fabricated into various shapes. It maintains its toughness even in a wide range of temperatures, making it a wonderfully versatile and dependable material for countless applications.
| Standard | ASTM A240, ASME SA240 |
| Thickness | 0.1mm to 12 mm Thk |
| Sheet/Plate Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching. |
| Finish | Hot rolled (HR), Cold rolled (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Galvanized etc. |
| Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
| SS 304L | min. | – | 8.0 | – | – | – | – | – | 18.0 | – |
| max. | 0.030 | 12.0 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 20.0 | ||
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304L | 485 | 40 | 170 | 92 | 201 |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
Grade | Density of ss304 in kg/m3 | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
304L | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 304L sheets and plates offer many advantages, including excellent corrosion resistance, especially in harsh environments such as chemical and coastal environments where 304L’s low carbon content increases and reduces its weldability risk of carbide precipitation, making it ideal for welding applications. It is very durable, stain resistant and requires little maintenance. 304L also has excellent strength and toughness at high and low temperatures. Its versatility makes it suitable for a wide range of industries, including food processing, pharmaceutical manufacturing and manufacturing.
You’ll find Stainless Steel 304L sheets and plates hard at work in so many areas of our daily lives. They are a cornerstone of the food and beverage industry, used for everything from processing equipment to restaurant kitchens because they are so easy to keep clean and sanitary. They are also essential in architectural projects for sleek railings and facades, in chemical plants for pipes and tanks, and even in pharmaceutical manufacturing. Their resilience makes them a perfect choice for environments where hygiene and longevity are absolutely paramount.
