From the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as your trusted partner for specialized materials, bringing strength and reliability directly to your projects. We take pride in supplying high-performance Monel K500 foils, meticulously sourced and crafted to meet the most demanding specifications. Our commitment is to provide not just a product, but a dependable solution that empowers innovation and ensures longevity in the most challenging environments, all backed by our local expertise and dedicated customer service.
Monel K500 is a high-strength nickel-copper alloy, uniquely strengthened with aluminum and titanium. This special composition gives it all the excellent corrosion resistance of its Monel 400 counterpart but with significantly enhanced mechanical properties. The foil form offers impressive tensile strength and yield strength, along with good ductility. It is also known for its ability to be age-hardened, allowing its hardness and strength to be precisely tuned through a specific heat treatment process to achieve the perfect balance for your application.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
DIN 2.4375 Foils offer numerous advantages, including superior strength and excellent resistance to corrosion, especially in marine environments, acids, and alkalis. Their high tensile and yield strength ensure durability and reliability under extreme stress and high temperatures. Monel K500 foils also exhibit outstanding resistance to stress corrosion cracking, pitting, and oxidation, making them ideal for use in harsh conditions. Additionally, they maintain excellent mechanical properties at elevated temperatures. Their ease of fabrication and welding further enhance their versatility, making them suitable for applications in aerospace, chemical processing and marine industries.
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | JIS | GOST | BS | EN |
| Monel k500 | 2.4375 | N05500 | – | – | – | – | – |
The unique combination of strength and corrosion resistance makes Monel K500 foil indispensable in demanding fields. You’ll find it essential in marine engineering for pump shafts and propeller blades, and in the oil and gas industry for components like scraper rings and valve parts that must withstand sour gas. Its non-magnetic properties are crucial for specialized electronics and marine instruments, while its reliability also makes it a preferred choice for springs, fasteners, and doctor blades in aggressive chemical processing environments where failure is not an option.
