Nestled in the industrial heart of Manila, Diaz Sheetsandplates has built a trusted reputation as a dedicated source for high-quality aluminium coils. We understand that the foundation of any great project lies in superior materials, which is why we focus on providing robust and reliable coils that meet the precise demands of various industries. Our commitment isn’t just to supply metal, but to deliver a product that ensures durability and performance, making us a preferred partner for businesses seeking dependable aluminium solutions right here in the Philippines.
Our aluminium coils are crafted from carefully selected alloys, primarily from the 1000, 3000, and 5000 series, to achieve an ideal balance of properties. This careful composition results in a material that boasts excellent corrosion resistance, good formability, and a commendable strength-to-weight ratio. Whether you need a softer, highly malleable coil for intricate work or a stronger, more resilient one for structural applications, we ensure the mechanical integrity of our product meets your specific requirements for tensile strength and elongation.
Standards : ASTM B209 / ASME SB209
Temper : O,H14,H16,H18,H19,H22,H24
Thickness : 0.1-4
Width : coil
Length : 100-1600
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Coil Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Coil
| Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI | |
| 1100 (min) | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
| 1100 (max) | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
| Alloy | Temper | UTS(Mpa) | % Elongation | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||
| 1100 | O | 75 | 110 | 20 | 25 | 29 |
| H12 | 95 | 130 | 5 | 6 | 7 | |
| H14 | 110 | 145 | 3 | 4 | 5 | |
| H16 | 130 | 165 | 2 | 3 | 4 | |
| H18 | 150 | — | 2 | 2 | 3 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium Coils offer numerous advantages, making them a preferred choice across industries. Their lightweight nature combined with high strength ensures easy handling and excellent structural integrity. They provide superior corrosion resistance, ideal for outdoor and marine applications. Aluminium coils also exhibit excellent thermal and electrical conductivity, enhancing their utility in heat exchangers and electrical systems. Their high ductility allows for easy forming and fabrication into various shapes. Additionally, they are environmentally friendly, being 100% recyclable, and offer cost-efficiency due to their durability and low maintenance requirements, ensuring long-term performance in diverse applications.
Yes, we offer custom sizes for Aluminium Coils to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
The versatility of aluminium coils makes them indispensable across a wide spectrum of uses. They are the essential starting point for creating durable roofing and cladding for buildings, sleek body panels for vehicles, and efficient heat exchangers in appliances. You’ll also find our coils transformed into everyday items like food packaging, kitchen utensils, and electronic housings. Essentially, wherever there’s a need for a lightweight, strong, and rust-resistant material, these coils provide the perfect solution, forming the backbone of countless products that shape our modern world.
