Diaz Sheetsandplates, based in the industrial heart of Manila, stands as your trusted partner for premium-grade stainless steel. We take pride in supplying the exceptional Stainless Steel 904L Angle, a material chosen for situations where standard steels simply won’t suffice. Our commitment is to provide not just a product, but a reliable solution for your most demanding projects, ensuring you have access to top-tier materials backed by local expertise and a dedication to quality that defines our name in the Philippine market.
The standout quality of 904L lies in its advanced composition, which includes a significant amount of chromium, nickel, and molybdenum, plus a purposeful addition of copper. This unique recipe grants it formidable resistance to a wide range of corrosive substances, particularly sulfuric acid. Mechanically, this translates to an angle that is not only incredibly durable but also offers excellent strength and toughness, even in challenging environments where pressure and temperature are significant factors.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness: 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| >SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 904L angle offers many advantages, including excellent corrosion resistance, especially in acidic environments, which makes it ideal for applications such as chemical processing, seawater handling and more etc. Highly resistant to pitting and crevice corrosion, ensuring durability in extreme conditions. The alloy offers excellent weldability and formability, making it versatile for a variety of structural applications. With increased strength and durability, the stainless steel 904L Angle maintains its integrity under extreme temperatures and pressures. The low carbon content reduces carbide precipitation and increases corrosion resistance in high-temperature environments.
This remarkable resistance makes the 904L angle indispensable in industries where failure is not an option. You’ll find it forming the structural backbone of chemical processing plants, pharmaceutical manufacturing equipment, and critical components in offshore oil and gas platforms. Its reliability also makes it a preferred choice for pollution control scrubbers, seawater cooling systems, and in the construction of tanks and piping meant to handle highly aggressive chemicals, ensuring long-term performance and safety.
