From the industrial heart of Manila, Diaz Sheetsandplates has built a reputation for providing high-quality steel solutions. We are proud to be a leading supplier of specialized materials like the Stainless Steel 17-7 PH Angle. This isn’t your average stainless steel; it’s a precipitation-hardening alloy that offers a unique combination of strength and corrosion resistance, making it an indispensable resource for industries across the Philippines that require reliability under demanding conditions.
The composition of stainless steel 17-7 PH includes chromium, nickel, and the key addition of aluminum. This blend allows the material to be heat-treated to achieve impressive mechanical properties. You can expect high strength and hardness, excellent toughness, and good corrosion resistance, all while maintaining a degree of ductility. It’s this well-rounded performance that makes it so valuable for structural applications where durability is non-negotiable.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness: 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Ni | Al | Cr | P | Si | S | Fe | |
| 17-7 PH | min. | – | – | 6.50 | 0.75 | 16 | – | – | – | – |
| max. | 0.09 | 1.0 | 7.75 | 1.50 | 18 | 0.040 | 1.0 | 0.030 | Balance | |
| Properties | Metric | Imperial |
| Tensile strength | 1170 MPa | 170000 psi |
| Yield strength | 965 MPa | 140000 psi |
| Modulus of elasticity | 204 GPa | 29600 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 6% | 6% |
| Hardness, Rockwell C | 38 | 38 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 17-7 PH | 1.4568 | S17700 | SUS 631 | Z8CNA17.07 | 301S81 | – | X7CrNiAl 17 7 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 17-7 PH (Precipitation Hardened) Angle offers several advantages. Combine excellent strength, superior fatigue resistance and excellent processing power. The material offers excellent corrosion resistance, making it ideal for harsh environments. It is also resistant to high temperatures and can withstand high temperatures without losing its mechanical properties. Stainless steel 17-7 PH Angle is widely used in aerospace, automotive, and construction applications due to its ability to heat treat to varying hardness while maintaining high performance and reliability while also saving cost which is less expensive.
You’ll often find this angled steel hard at work in critical areas. Its toughness makes it perfect for structural frameworks, sturdy brackets, and mechanical components in chemical plants. The aerospace and automotive industries also rely on it for parts that must endure stress without failing. Essentially, wherever a project demands a material that can be both incredibly strong and reliably corrosion-resistant over the long haul, the 17-7 PH Angle proves to be an outstanding choice.
