Diaz Sheetsandplates, based right here in Manila, stands as your trusted partner for premium stainless steel solutions. We take pride in supplying high-quality Stainless Steel 17-4 PH Angle, a premier material chosen for its exceptional performance. This isn’t your average stainless; it’s a precipitation-hardening grade that offers a remarkable blend of strength and corrosion resistance, making it a superior choice for demanding projects across the Philippines. When you need reliability and durability, our 17-4 PH Angle delivers.
The composition of this steel is a careful balance, primarily chromium and nickel, but it’s the addition of copper that truly empowers it. Through a specific heat treatment process, it achieves impressive mechanical properties. This means the 17-4 PH Angle offers high strength and hardness, all while maintaining good toughness. It’s this unique ability to be strong without becoming brittle that makes it such a versatile material for critical applications where both durability and reliability are non-negotiable.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness: 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | P | Si | Ni | Cu | Fe | Mn | S | Cr | Cb+Ta |
| SS 17-4 PH | 0.07 | 0.04 | 1.0 max | 3.0 – 5.0 | 3.0 – 5.0 | Bal | 1.0 max | 0.03 | 15.0 – 17.5 | 5 X C / 0.45 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 17-4 PH angle (Precipitation Hardening) surface offers several advantages. It combines high strength with excellent corrosion resistance, especially in harsh environments such as chemical and marine applications. Its excellent room and high temperature mechanical properties make it ideal for aerospace, the oil and gas industry and food processing. The alloy also exhibits improved stability and resistance to stress corrosion cracking. Moreover, 17-4 PH stainless steel is easily machined and can be heat-hardened, providing flexibility in a variety of industrial applications and providing durability and versatility it is reliable in complex materials.
You’ll often find the Stainless Steel 17-4 PH Angle hard at work in environments that demand resilience. It’s perfect for constructing crucial components in the aerospace and automotive industries, as well as in heavy machinery. Think of it being used for gears, valves, pumps, and other parts that face constant stress or corrosive elements. Essentially, wherever a standard stainless steel might falter under pressure, the 17-4 PH Angle is the go-to choice to ensure long-lasting performance and integrity.
