From the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as your trusted partner for robust steel solutions. We take pride in manufacturing and supplying premium C60 High Carbon Steel sheets and plates, delivering exceptional quality and reliability directly to fabricators and industries across the Philippines. Our commitment is to provide materials that form the strong, dependable backbone of your most demanding projects, backed by local expertise and a dedication to supporting the growth of our nation’s infrastructure and manufacturing sectors.
C60 steel earns its reputation through a specific composition, primarily featuring a higher carbon content that is key to its strength. This is balanced with manganese to enhance its hardenability, resulting in a material that can be effectively heat-treated. After proper tempering, it achieves an excellent combination of high tensile strength and good wear resistance. While it is less ductile than milder steels, this trade-off is what makes it perfectly suited for applications where durability and the ability to withstand significant stress are the top priorities.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Grade |
C |
Mn |
P |
S |
Si |
Cr |
Mo |
Ni |
Cr+Mo+Ni |
C60/1.0601 |
0.57-0.65 |
0.60-0.90 |
≤ 0.045 |
≤ 0.045 |
≤ 0.4 |
≤ 0.4 |
≤ 0.1 |
≤ 0.4 |
≤ 0.63 |
C60E/1.1221 |
0.57-0.65 |
0.60-0.90 |
≤ 0.03 |
≤ 0.035 |
≤ 0.4 |
≤ 0.4 |
≤ 0.1 |
≤ 0.4 |
≤ 0.63 |
C60R/1.1223 |
0.57-0.65 |
0.60-0.90 |
≤ 0.03 |
0.02-0.04 |
≤ 0.4 |
≤ 0.4 |
≤ 0.1 |
≤ 0.4 |
≤ 0.63 |
Mechanical properties a at room temperature in the quenched and tempered condition (+QT) |
|||
Diameter d mm |
≤ 16 |
16-40 |
40-100 |
Thickness t mm |
< 8 |
8-20 |
20-60 |
Yield Strength Mpa |
≥580 |
≥520 |
≥450 |
Tensile Strength Mpa |
850-1000 |
800-950 |
750-900 |
Elongation, % |
≥11 |
≥13 |
≥14 |
Reduction of area ,% |
≥25 |
≥30 |
≥35 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
C60 High Carbon Steel Plates offer several advantages, including outstanding strength and hardness, making them ideal for heavy-duty applications. Their high tensile and yield strength provide excellent load-bearing capabilities, while their wear resistance ensures long-lasting durability, even in harsh conditions. These plates also exhibit good machinability, allowing for precise fabrication to meet specific design requirements. The toughness of C60 steel ensures it resists deformation under high stress. Cost-effective and reliable, C60 High Carbon Steel Plates are widely used in automotive, manufacturing, and construction industries, delivering consistent performance in demanding environments.
Yes, we offer custom sizes for C60 High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
USA |
Philippines |
China |
Japan |
Australia |
1060 |
070M60 |
60# |
S60C |
1060 |
The remarkable strength of C60 High Carbon Steel makes it the material of choice for a wide array of critical components. You will commonly find it used in heavy-duty springs, high-stress blades, and various cutting tools that must maintain a sharp edge. It is also indispensable in the manufacturing of gears, shafts, and other machinery parts that experience constant friction and load. Essentially, wherever a project demands a part that can resist abrasion and bear substantial weight without deforming, C60 sheet and plate provide the necessary resilience and longevity.
