Browse Our Collection
Get instant quotes that fit your budget perfectly.
From the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as your trusted partner for robust steel solutions. We take pride in manufacturing and supplying premium C55 High Carbon Steel sheets and plates, engineered to meet the demanding challenges of various sectors. Our commitment lies in delivering not just a product, but a foundation of strength and reliability for your most critical projects, ensuring you have a local source for quality that you can count on.
C55 steel derives its notable strength from a carefully balanced composition, primarily consisting of carbon, manganese, and silicon. This specific blend gives the material exceptional mechanical properties, including high tensile strength and impressive wear resistance. While it is less ductile than lower-carbon steels, this very characteristic makes it exceptionally durable and capable of withstanding significant impact and abrasion, making it a go-to choice for applications where toughness is non-negotiable.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Element |
C |
Si |
Mn |
P |
S |
Cr |
Cu |
Ni |
Content (%) |
0.47 – 0.55 |
0.17 – 0.37 |
0.50 – 0.80 |
0.03 |
0.03 |
0.15 |
0.25 |
0.30 |
GRADE |
Tensile Strength min |
Yield Strength min |
Elongation min. |
contraction min |
impact min |
Hardness Max |
|
σb/M Pa |
σs/M Pa |
δ5/% |
ψ/% |
Akv/J |
Without heating |
annealing |
|
C50 |
630 |
375 |
14 |
40 |
31 |
241 |
207 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
C55 High Carbon Steel Plates offer numerous advantages, including exceptional strength and hardness, making them ideal for demanding industrial applications. These plates provide excellent wear resistance, ensuring durability even under high-stress conditions. With high tensile and yield strength, C55 steel supports heavy load-bearing and is perfect for use in machine components like gears, shafts, and tools. Its good machinability allows for precise fabrication, while its toughness makes it resistant to deformation. Cost-effective and long-lasting, C55 High Carbon Steel Plates deliver reliable performance in construction, automotive, and manufacturing industries.
Yes, we offer custom sizes for C55 High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| SAE / AISI – American | SAE 1050 |
| DIN – Germany | C50 / CK50 |
| EN – English / BS – British | – |
| JIS – Japanese | S50C |
| UNI – Italy | C50 |
The remarkable durability of C55 High Carbon Steel makes it indispensable for a wide range of heavy-duty applications. You’ll commonly find it forming the backbone of industrial machinery, heavy-duty springs, and high-strength blades for cutting tools. It’s also the preferred material for crafting durable agricultural implements, robust construction components, and various parts in the automotive industry that must endure constant stress and friction, proving its versatility and critical role in building and manufacturing.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
