For those demanding exceptional performance in the most unforgiving environments, Diaz Sheetsandplates stands as your trusted partner in Manila. We specialize in supplying high-quality Rene 41 foil, a material engineered for resilience. Our commitment goes beyond mere supply; we understand the critical nature of your projects and provide a reliable source for this advanced superalloy, ensuring you have the right material to push the boundaries of engineering and innovation right here in the Philippines.
Rene 41 foil is a nickel-cobalt-chromium superalloy strengthened by a high volume of precipitates. Its key characteristic is an outstanding balance of high tensile and creep-rupture strength, which it maintains at temperatures up to 1800°F (980°C). This impressive strength is coupled with excellent oxidation resistance, making it a go-to material for applications where both mechanical integrity and surface stability are non-negotiable under extreme thermal stress.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Rene 41 foil offers numerous advantages, making it a preferred material for demanding applications. It excels in high-temperature environments, maintaining strength and stability up to 980°C (1800°F). The alloy’s exceptional creep resistance ensures reliability under prolonged stress, while its high tensile strength enhances durability. Rene 41 is also highly resistant to oxidation and corrosion, extending the lifespan of components in harsh conditions. Additionally, its precision and adaptability make it ideal for aerospace, gas turbines, and industrial applications requiring exceptional performance under extreme thermal and mechanical stresses.
Yes, we offer custom sizes for Rene 41 Foil to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
The unique properties of Rene 41 foil make it indispensable in aerospace and other high-tech industries. You’ll find it forming critical components like jet engine turbine seals, combustion liners, and exhaust assemblies, where heat and pressure are immense. Beyond flight, its reliability is crucial in heat-treating fixtures, chemical processing equipment, and even in the demanding environments of motorsports. Essentially, it’s the material of choice when failure is not an option and performance under extreme duress is the primary requirement.
