In the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as a trusted source for precision-engineered materials, with our Permalloy Foil representing a cornerstone of our specialized offerings. We understand that innovation in electronics and technology demands materials of exceptional quality and reliability. That’s why we are dedicated to supplying this unique nickel-iron alloy foil, meticulously produced to meet the exacting standards required for sensitive magnetic applications, ensuring your projects are built on a foundation of excellence and consistency right here in the Philippines.
This specialized foil is primarily a nickel-iron alloy, often with an 80% nickel and 20% iron composition, which is key to its remarkable magnetic personality. What truly sets it apart are its soft magnetic properties; it possesses high magnetic permeability, meaning it can easily support the formation of magnetic fields, while exhibiting very low coercivity, which allows it to be magnetized and demagnetized with minimal effort. This combination, along with negligible magnetic hysteresis, makes it incredibly efficient for controlling magnetic flux.
| Standard Specification : | |
| Dimensions : | – |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo | Fe |
| 1J50 | 0.010 | 0.17 | 0.35 | 0.006 | 0.005 | 49.80 | 0.02 | —— | Bal |
| 1J79 | 0.010 | 0.38 | 0.85 | 0.005 | 0.003 | 79.50 | 0.02 | 3.95 | Bal |
| 1J85 | 0.010 | 0.18 | 0.35 | 0.005 | 0.003 | 80.30 | 0.02 | 4.95 | Bal |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Permalloy foil offers exceptional magnetic properties, including high permeability and low coercion, making it ideal for protection of sensitive electrical components against electromagnetic interference (EMI) Its magnetic shrinkage properties a ideally ensures minimal changes in shape under magnetic influence, increasing the stability. High saturation magnetization of the alloy provides effective power transfer between transformers and inductors. Its corrosion resistance and heat stability make it suitable for harsh environments. The versatility of permalloy foil allows for use in precision instrumentation, medical device and aerospace applications, providing reliability, efficiency and durability in harsh environments.
The practical uses for Permalloy Foil are both fascinating and vital, particularly in shielding sensitive electronics from disruptive magnetic fields. You’ll find it carefully integrated into transformers, inductors, and magnetic recording heads to enhance performance and efficiency. Its ability to create effective magnetic shields makes it indispensable in devices ranging from smartphones and medical imaging equipment like MRI scanners to aerospace avionics, ensuring clarity and precision by protecting critical components from external interference.
