Located in the industrial heart of Manila, Philippines, Diaz Sheetsandplates has built a strong reputation as a trusted partner for industries requiring exceptional materials. We take pride in specializing in the supply and distribution of Nickel Alloy 201 sheets and plates, providing a crucial solution for applications where purity and reliability are non-negotiable. Our commitment is to deliver not just a product, but a durable and high-performance foundation for your most demanding projects, backed by local expertise and a dedication to quality that our clients have come to depend on.
Nickel Alloy 201 is distinguished by its high nickel content, over 99%, making it exceptionally pure. This composition gives it outstanding resistance to corrosion, especially in caustic environments and certain acids. Mechanically, it offers excellent ductility and toughness, even at very low temperatures, and retains its strength under high heat. It’s a material known for its reliability and formability, providing a stable and durable performance in conditions where many other metals would quickly falter, ensuring long-term structural integrity for demanding applications.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates offer excellent corrosion resistance, particularly in acidic and alkaline environments. They are highly resistant to oxidation and possess superior thermal and electrical conductivity. These alloys are known for their excellent formability, allowing easy shaping and welding. With outstanding mechanical properties at high and low temperatures, Nickel Alloy 201 is ideal for chemical processing, heat exchangers, and electronics applications. It also provides strength and stability, making it suitable for harsh environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
The unique properties of Nickel Alloy 201 make it indispensable across several key industries. It is extensively used in the chemical processing sector for handling caustic soda and other corrosive chemicals. You’ll also find it in food processing equipment, where its purity prevents contamination, and in aerospace components that must perform reliably in extreme conditions. From electrical and electronics applications to heat treatment fixtures and furnace components, this alloy provides a trusted solution for environments that demand uncompromising resistance to corrosion and thermal stability.
