From the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as your trusted partner for high-performance metals. We specialize in supplying premium Maraging Steel 250, 300, and 350 sheets, delivering the exceptional strength and reliability that modern engineering demands. Our commitment goes beyond just supply; we ensure that every sheet meets rigorous standards, providing local industries with the robust materials needed to build groundbreaking products and tackle the most challenging projects with confidence.
The unique composition of these steels features a low-carbon, iron-nickel base with key additions like cobalt, molybdenum, and titanium. This special recipe allows them to develop their incredible strength not through carbon, but through a specialized heat treatment called “maraging.” This process precipitates intermetallic compounds within the metal, resulting in an outstanding combination of ultra-high tensile strength, good toughness, and impressive fracture resistance, all while maintaining relatively simple fabrication characteristics.
| Specification : | ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101 |
| Standard : | AMS, AMS, API |
| Size : | 20mm x 1200 x 500 |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000) |
| Weight% | C | Si | Mn | S | P | Co | Ni | Mo | Ti | Al | Fe |
| Maraging 300 | 0.03 max | 0.10 max | 0.10 max | 0.010 max | 0.010 max | 8.0-9.5 | 18.0-19.0 | 4.6-5.2 | 0.55-0.80 | 0.05-0.15 | Bal |
| Material | 0.2 % Yield Strength ksi | Ultimate Tensile Strength ksi | Elongation in 4D(%) | Reduction of Area % | Hardness Rc |
| Maraging 300, Solution Annealed 1500° F (816°C), 1hr, AC | 120 | 150 | 16 | 70 | 30 |
| Solution Annealed Plus Aged 900 ° F (482°C), 3 hrs AC | 280 | 290 | 8 | 40 | 52 |
| STANDARD | UNS | Material No | AMS | ASTM | Mil-S | BS | DTD | MSRR |
| Maraging Steel | K92890, K93120, S35000 | – | 6512 | A538 | 46850D | S162 | 5212 | 6551 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Marraging steel 250/300/350 sheets and plates provide exceptional strength and toughness, making them ideal for aerospace, equipment, and defense applications They provide excellent machinability in the annealed state and exhibit excellent resistance to cracking and fatigue. Their low-carbon design ensures maximum distortion when heat treated, while the high nickel content increases corrosion resistance. Steel inserts are easily welded together, offering versatility in construction. These materials retain their mechanical properties even at elevated temperatures, providing reliability in harsh environments. Its durability and longevity make it cost-effective for critical applications..
The remarkable properties of Maraging Steel sheets make them indispensable in fields where failure is not an option. You’ll find them forming the backbone of critical aerospace components like rocket motor cases and landing gear, as well as in high-stress tooling for injection molding and die casting. Their reliability also extends to the defense sector for armored vehicles and in specialized manufacturing for shafts and parts that must withstand extreme pressures and demanding environments day after day.
