Diaz Sheetsandplates, a reputable manufacturer and supplier located in Manila, Philippines, is well-known for its high-quality Alloy C263 Sheets and Plates, which are engineered for top-notch performance in demanding industrial settings. These plates are produced using cutting-edge manufacturing techniques that guarantee exceptional strength, durability, and resistance to high temperatures and oxidation. With a strong focus on quality and customer satisfaction, Diaz Sheetsandplates provides products that adhere to international standards, serving industries like aerospace, chemical processing, and power generation, where reliability and corrosion resistance are crucial for operational efficiency.
Alloy C263 Sheets and Plates are primarily made up of nickel, cobalt, chromium, and molybdenum, with added titanium and aluminum to boost precipitation hardening. They showcase impressive mechanical properties, including high tensile and yield strength, excellent creep and rupture resistance, and remarkable oxidation resistance even at elevated temperatures. These characteristics make Alloy C263 perfect for components that need to endure extreme thermal and mechanical stress while keeping their structural integrity and corrosion resistance in harsh environments.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | UNS | Workstoff | AMS |
| Alloy C263 | N07623 | 2.4650 | 5872 |
Alloy C263 sheets and plates provide excellent resistance to high temperature oxidation, corrosion and carburization, making them ideal for harsh environmental applications such as gas turbines and chemical processes They exhibit excellent strength and durability maintain performance at high temperatures, ensuring reliability in extreme conditions. The resistance of the alloy to creep and thermal fatigue cracking increases the life of the components. C263 is also known for its excellent weldability, formability and durability, making it suitable for complex industrial applications. Its ability to maintain structural integrity under stress enhances its value in critical engineering and construction applications.
Alloy C263 sheets and plates are widely used in high temperature and high pressure applications due to excellent oxidation and corrosion resistance Typically found in aerospace, medical systems, power generation these materials and used for turbine blades, combustion chambers and heat exchangers Their manufacturing capabilities withstand extreme temperatures Makes them ideal for use, where Nuclear reactors, gas turbines and exhaust are available systems, where energy and durability are important.
